• Full CNC Carbide Saw Blade Back Angle Grinding Machine LDX-021
Full CNC Carbide Saw Blade Back Angle Grinding Machine LDX-021

Full CNC Carbide Saw Blade Back Angle Grinding Machine LDX-021

Product Details:

Place of Origin: Foshan, Guangdong, China
Brand Name: Lidexin
Certification: CU,ISO
Model Number: LDX-027

Payment & Shipping Terms:

Minimum Order Quantity: 1 unit
Price: Western Union
Packaging Details: Mechanical dimensions (L X W X H mm) : 800X800X1380
Delivery Time: 10-15 work days
Payment Terms: T/T, Western Union
Supply Ability: 100pcs/mon
Get Best Price Contact Now

Detail Information

Saw Blade Width:: 27-100mm Working Speed: Maximum 18 Teeth/min
Grinding Wheel Line Speed: 26m/s Coolant Pump Flow Rate: 501
High Light:

cnc automatic grinding machine

,

cnc 4 inch saw blade for grinder

,

ldx-021 automatic grinding machine

Product Description

LDX-021 Full CNC Carbide Saw Blade Back Angle Grinding Machine



Circular saw blade rotation elastic adjustment:



1,If the rotation of the saw blade is not properly relaxed, the forward displacement of the saw blade will not be allowed at this time, so when the saw blade is installed, rotate the circular saw blade with the left hand counterclockwise direction to test the rotation tightness, if the tightness is improper, adjust the anti-loosening nut with the M17 open wrench to make the rotation tightness of the saw blade appropriate.



2,In order to make the grinding of the teeth equal up and down, the center of the grinding wheel and the thickness of the saw blade should be in a straight line.



3,Before grinding, it should be decided whether to grind the high and low teeth. If you want to grind the high and low teeth, adjust the low and high teeth difference adjustment lever to the required scale.









Technical parameter:
Processing saw blade thickness: 0.6-3mm
Saw blade width: 27-100mm
Working speed: Maximum 18 teeth/min
Grinding wheel size (outer diameter X hole) : ¢125mmX32mm
Grinding wheel line speed: 26m/s
Coolant pump flow rate: 501
Coolant cylinder volume: 80L
Total power: 2KW
Voltage: three-phase 380V
Mechanical weight: 300KG
Mechanical dimensions (L X W X H mm) : 800X800X1380

Grinding object:
Alloy band saw blade, bimetal band saw blade, frame saw blade, width 27mm-150mm can be used. Can grind all kinds of tooth shape, such as 3-4 teeth, 4/6 teeth, variable teeth and equal teeth, etc. The machine is simple and convenient to operate, suitable for large, medium and small machinery factory, wood processing, steel sawing processing plant, alloy band saw blade, bimetal band saw blade, frame saw blade tooth shape grinding indispensable equipment.





Full CNC Carbide Saw Blade Back Angle Grinding Machine LDX-021 0







Full CNC Carbide Saw Blade Back Angle Grinding Machine LDX-021 1
