LDX-026A Grinding Diameter 400-2000MM CNC Circular Saw Blade Grinding Machine Factory Wholesale
Product Details:
| Place of Origin: | Foshan, Guangdong, China |
| Brand Name: | Lidexin |
| Certification: | CU,ISO |
| Model Number: | LDX-026A |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 unit |
|---|---|
| Price: | Western Union |
| Packaging Details: | Mechanical dimensions (length x width x height): 1800X1400X1800mm |
| Delivery Time: | 10-15 work days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100pcs/mon |
|
Detail Information |
|||
| Saw Blade Aperture: | ￠ 10-220mm | Tooth Pitch: | 7-120mm |
|---|---|---|---|
| Tooth Surface Angle: | 5 Degrees To+30 Degrees | Grinding Speed: | 0.5-6mm/s |
| Processing Saw Blade Diameter Range: | ￠300- ￠ 2000mm | Tooth Top Back Angle: | 6-45 Degrees |
| Highlight: | CNC Circular Saw Blade Grinding Machine,Circular Saw Blade Grinding Machine Factory |
||
Product Description
LDX-026A Grinding diameter 400-2000MM CNC circular saw blade grinding machine factory wholesale
How to use multi-blade saw gear grinding machine:
1,First of all, the grinding wheel lift is adjusted to the lowest, the saw blade is installed on the saw blade seat, a good pressure plate, turn the handwheel, the saw blade is driven by the lead screw to move up and down the saw blade is adjusted to more than 30~50 mm of the pressure head, and the pressure head is compressed.
2,Adjust the serrated position at the end of the gear shift and align the grinding wheel with the serrated saw blade. Then adjust the grinding wheel to the grinding * position to start grinding.
3,Grinding wheel Angle adjustment: to adapt to grinding saw blades with different serrated front angles. The Angle of the wheel mounting plate can be adjusted. The method is to loosen the two bolts of the mounting seat plate of the grinding wheel holder (do not remove the nuts) and then rotate the grinding wheel holder in a clockwise direction. Turn so that the front end of the grinding wheel, when the saw blade feed grinding, can contact the entire plane of the front corner of the tooth (from the tip of the tooth to the root of the tooth).
CNC circular saw blade grinding machine suitable for what industry:
1,In the process of wood processing, circular saw blades are commonly used as cutting tools. The CNC circular saw blade grinding machine can precisely grind the teeth of the saw blade, ensure the cutting quality and efficiency of the saw blade, and meet the needs of the wood processing industry for high-precision saw blades.
2,The wood-based panel manufacturing process also needs to use circular saw blades for cutting. The high efficiency grinding ability of CNC circular saw blade grinding machine helps to improve the production efficiency and quality of wood-based panels.
3,Furniture manufacturing process involves a lot of wood cutting work, CNC circular saw blade grinding machine can ensure the sharpness and durability of the saw blade, so as to improve the accuracy and efficiency of furniture manufacturing.
| Technical parameters: |
| Processing saw blade diameter range: ￠300- ￠ 2000mm |
| Saw blade aperture: ￠ 10-220mm |
| Saw blade thickness (steel plate): 1-12mm |
| Tooth pitch: 7-120mm |
| Tooth surface angle: 5 degrees to+30 degrees |
| Tooth top back angle: 6-45 degrees |
| Left and right inclination of teeth: tooth tip/tooth surface 45 degrees |
| Blade grinding stroke range: maximum 25mm (adjustable) teeth/minute |
| Grinding speed: 0.5-6mm/s |
| Working speed: maximum 20 teeth/minute |
| Grinding wheel size (outer diameter x hole): (￠ 125mm x ￠32mmX1mm) |
| Negative chamfer grinding: -27 degrees |
| Grinding head rotatable angle: 90 degrees and 180 degrees |
| Grinding wheel linear speed: 26m/s |
| Flow rate of coolant water pump: 501/min |
| Volume of coolant cylinder: 85L |
| Total power: 2.2 kW |
| Voltage: three-phase 380v |
| Mechanical weight: 1200KG |
| Mechanical dimensions (length x width x height): 1800X1400X1800mm |
| Technical features: |
| The design of this machine refers to the characteristics of similar domestic and foreign models, absorbs and analyzes the advantages of the same type, and makes some functional improvements. This equipment is specifically designed for grinding large alloy saw blades. |
| 1. Pre set multiple sets of tooth profiles for one click multifunctional operation. |
| 2. The flat teeth of the ladder can be completed in one go, with CNC grinding and any tooth shape, which can increase efficiency by three times; Improved gear extraction operation to improve accuracy and extend service life. |
