• Grinding Diameter 300-1800MM TCT Saw Blade Sharpening Machines LDX-026A
Grinding Diameter 300-1800MM TCT Saw Blade Sharpening Machines LDX-026A

Grinding Diameter 300-1800MM TCT Saw Blade Sharpening Machines LDX-026A

Product Details:

Place of Origin: Foshan, Guangdong, China
Brand Name: Lidexin
Certification: CU,ISO
Model Number: LDX-026A

Payment & Shipping Terms:

Minimum Order Quantity: 1 unit
Price: Western Union
Delivery Time: 10-15 work days
Payment Terms: T/T, Western Union
Supply Ability: 100pcs/mon
Get Best Price Contact Now

Detail Information

Tooth Surface Angle: 5 Degrees To+30 Degrees Grinding Speed: 0.5-6mm/s
Working Speed: Max. 20 Teeth/min Volume Of Coolant Cylinder: 85L
High Light:

300-1800mm tct saw blade sharpening machines

,

tct saw blade sharpening machines ldx

,

300-1800mm angle grinder saw blades

Product Description



LDX-026A Grinding diameter 300-1800MM TCT saw blade sharpening machines





Automatic grinding machine grinding features::



1,Alloy saw blade as an industrial consumable, sawing for a long time, there will be many problems: such as blunt head, cutting is not sharp enough; There are lines and burrs on the surface of the cutting workpiece, and the material loss is larger; The sawing sound is noisy and uneven; The serrations are not sharp causing the cut to be smoky and so on.



2,Because the cutting workpiece requirements are relatively high, worried about the quality of the workpiece cut out after the alloy saw blade grinding, so adhere to the principle of only buying new films and never grinding the saw blade.



3,The alloy saw blade itself is more complex than the ordinary cutting tool, and is composed of the saw plate and the cutting head. The problems after the use of alloy saw blades are also different, and they need to be targeted.







Technical parameters:
Processing saw blade diameter range: ¢300- ¢ 1800mm
Saw blade aperture: ¢ 10-220mm
Saw blade thickness (steel plate): 1-12mm
Tooth pitch: 7-120mm
Tooth surface angle: 5 degrees to+30 degrees
Tooth top back angle: 6-45 degrees
Left and right inclination of teeth: tooth tip/tooth surface 45 degrees
Blade grinding stroke range: maximum 25mm (adjustable) teeth/minute
Grinding speed: 0.5-6mm/s
Working speed: maximum 20 teeth/minute
Grinding wheel size (outer diameter x hole): (¢ 125mm x ¢32mmX1mm)
Negative chamfer grinding: -27 degrees
Grinding head rotatable angle: 90 degrees and 180 degrees
Grinding wheel linear speed: 26m/s
Flow rate of coolant water pump: 501/min
Volume of coolant cylinder: 85L
Total power: 2.2 kW
Voltage: three-phase 380v
Mechanical weight: 1200KG
Mechanical dimensions (length x width x height): 1800X1400X1800mm
Technical features:
The design of this machine refers to the characteristics of similar domestic and foreign models, absorbs and analyzes the advantages of the same type, and makes some functional improvements. This equipment is specifically designed for grinding large alloy saw blades.
1. Pre set multiple sets of tooth profiles for one click multifunctional operation.
2. The flat teeth of the ladder can be completed in one go, with CNC grinding and any tooth shape, which can increase efficiency by three times; Improved gear extraction operation to improve accuracy and extend service life.
