LDX-027 FUll CNC Band Saw Blade Back Angle Grinding Machine
Product Details:
| Place of Origin: | Foshan, Guangdong, China |
| Brand Name: | Lidexin |
| Certification: | CU,ISO |
| Model Number: | LDX-027 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 unit |
|---|---|
| Price: | Western Union |
| Packaging Details: | Mechanical dimensions (L X W X H mm) : 1600X900X1900 |
| Delivery Time: | 10-15 work days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100pcs/mon |
|
Detail Information |
|||
| Grinding Wheel Line Speed: | 26m/s | Total Power: | 4.5KW |
|---|---|---|---|
| Mechanical Weight: | 900KG | Processing Saw Blade Thickness: | 0.6-3mm |
| Saw Blade Width: | 27-150mm | Mechanical Dimensions (L X W X H Mm): | 1600X900X1900 |
| Highlight: | CNC Blade Back Angle Grinding Machine,4.5KW Blade Back Angle Grinding Machine |
||
Product Description
LDX-027 FUll CNC Band Saw Blade Back Angle Grinding Machine
What are the grinding methods of alloy band saw blade:
1,Saw blade used for a long time, the tooth tip will wear, sometimes just used for a period of time will also appear wear,
2,This may be because the new saw blade has not run together, the hardness of the sawn material is high, the slag inclusion hard point when sawing, the sawdust has not been removed at the edge, and the selected tooth shape is too small, which needs to be ground before continuing to use.
3,The common grinding methods of alloy band saw blade are band saw blade grinding machine, file to file the band saw blade, Angle grinder grinding blade, small grinder teeth grinding,
Saw blade grinding machine The use of sawtooth grinding machine:
1,Adjust the position of the center axis by observing the size of the grinding disc. If a large saw blade needs to be polished, gently rotate the center shaft to the side close to the grinding blade; If sharpening a small saw blade, it needs to be adjusted away from the sharpening blade.
2,Push the center shaft to the right end to provide sufficient clearance for subsequent blade installation.
3,Next, the saw blade is installed, and then by rotating the hand wheel, the initial position of the grinding surface of the saw is positioned to ensure that the contact Angle with the grinding wheel is accurate.
4,Then, it is critical to adjust the grinding Angle. By rotating the table, the Angle of the sawtooth grinding surface is carefully adjusted to form an ideal intersection Angle with the working face of the grinding wheel, which will directly affect the quality and efficiency of grinding.
5,Finally, make sure that the feed Angle of the grinding surface is also adjusted to the best, which usually means that the grinding surface is relative to the feed direction of the grinding wheel, and a proper Angle can ensure uniform wear and cutting effect of the teeth.
| Technical parameter: |
| Processing saw blade thickness: 0.6-3mm |
| Saw blade width: 27-150mm |
| Working speed: Maximum 18 teeth/min |
| Feed stroke: 1-28mm(variable speed) |
| Variable speed: 0.5-6mm/s |
| Grinding wheel size (outer diameter X hole) : ￠125mmX32mm |
| Grinding wheel line speed: 26m/s |
|
Coolant pump flow rate: 501 Coolant cylinder volume: 80L |
| Total power: 4.5KW |
| Voltage: three-phase 380V |
| Mechanical weight: 900KG |
| Mechanical dimensions (L X W X H mm) : 1600X900X1900 |
|
The main grinding objects of this machine: TCT band saw blade, bimetal band saw blade, frame saw blade, width 27mm-150mm can be used. This CNC machine is suitable for all kinds of tooth pitch, tooth shape grinding, such as 3/4 teeth, 4/6 teeth, variable pitch teeth and equidistant teeth. With automatic cutting fluid transmission function, can effectively reduce the high temperature generated in the grinding process of the alloy sawtooth, prevent the sawtooth welding, cutting fluid also has the role of cleaning grinding, which is beneficial to improve the grinding quality and extend the service life of the diamond wheel. The equipment has been widely used in wood processing plants, mechanical processing, alloy saw blade grinding services and other industries. This machine tool is easy to operate, convenient, suitable for all kinds of machinery processing plants, wood processing plants and other materials sawing processing plants: alloy band saw blade, bimetal band saw blade, frame saw blade grinding service enterprises indispensable equipment. Humanized dialogue interface, so that the user is more convenient, the installation of imported precision cross guide rail to control the lifting, effectively improve the precision of saw blade grinding, hydraulic saw blade automatic expansion system, so that the saw blade is always in the best working state, to ensure the grinding quality. |
