• 150-1200MM TCT Circular Saw Blade Front And Rear Angle Grinding Machine
150-1200MM TCT Circular Saw Blade Front And Rear Angle Grinding Machine

150-1200MM TCT Circular Saw Blade Front And Rear Angle Grinding Machine

Product Details:

Place of Origin: Foshan, Guangdong, China
Brand Name: Lidexin
Certification: CU,ISO
Model Number: LDX-020A

Payment & Shipping Terms:

Minimum Order Quantity: 1 unit
Price: Western Union
Packaging Details: Mechanical dimensions (length x width x height): 1600X1100X1800mm
Delivery Time: 10-15 work days
Payment Terms: T/T, Western Union
Supply Ability: 100pcs/mon
Get Best Price Contact Now

Detail Information

Saw Blade Aperture: ¢150- ¢1200mm Saw Blade Thickness (steel Plate): 1-12mm
Total Power: 1.85 KW Grinding Wheel Size (outer Diameter X Hole): (¢ 125mm X ¢ 32mmX1mm)
High Light:

ldx-020a tct saw blade grinding machine

,

ldx-020a 4 inch saw blade for grinder

,

150-1200mm tct saw blade grinding machine

Product Description

LDX-020A Grinding Diameter 150-1200MM TCT Circular Saw Blade Front And Rear Angle Grinding Machine



The gear grinding machine is operated correctly:

1,Before operation, you must wear protective equipment, such as safety helmet, protective glasses, protective gloves and protective shoes to ensure the safety of the operator. At the same time, check whether the power plug of the device is firmly connected, whether the power cable is damaged, whether the workbench is stable and stable, and whether the grinding disc is correctly and firmly installed.

2,TCT circular saw blade automatic tooth grinding machine may encounter some common problems in use, such as tooth shape, tooth number is not correct or teeth are not sharp, sawing sound is abnormal, sawing material is not vertical, wave sawing, sawtooth thickness is not equal, sawtooth edge is dark, polluted and so on

3,These problems need to be solved on a case-by-case basis, such as re-grinding teeth, checking and correcting the amount of sawn wood, cleaning and grinding sawtooth structural components.









Technical parameters:
Processing saw blade diameter range: ¢200- ¢1200mm
Saw blade aperture: ¢10-220mm
Saw blade thickness (steel plate): 1-12mm
Tooth pitch: 7-110mm
Tooth surface angle: 5 degrees to+20 degrees
Tooth top back angle: 1-20 degrees
Left and right inclination of teeth: tooth tip/tooth surface 20 degrees
Blade grinding stroke range: maximum 25mm (adjustable) teeth/minute
Grinding speed: 0.5-6mm/s
Working speed: maximum 20 teeth/minute
Grinding wheel size (outer diameter x hole): (¢ 125mm x ¢ 32mmX1mm)
Negative chamfer grinding: -15 degrees
Grinding wheel linear speed: 26m/s
Flow rate of coolant water pump: 501/min
Volume of coolant cylinder: 85L
Total power: 1.85 kW
Voltage: three-phase 380v
Mechanical weight: 800KG
Mechanical dimensions (length x width x height): 1600X1100X1800mm

Technical features:

1. This equipment can grind aluminum TCT cutting TCT saw blades, woodworking saw blades, and large alloy saw blades. It is easy to operate and can fully extend the service life of alloy saw blades. Each blade can be reused 15-30 times. This equipment has received praise from many buyers.





150-1200MM TCT Circular Saw Blade Front And Rear Angle Grinding Machine 0







150-1200MM TCT Circular Saw Blade Front And Rear Angle Grinding Machine 1







150-1200MM TCT Circular Saw Blade Front And Rear Angle Grinding Machine 2







150-1200MM TCT Circular Saw Blade Front And Rear Angle Grinding Machine 3







150-1200MM TCT Circular Saw Blade Front And Rear Angle Grinding Machine 4
